Autodesk InfoDrainage Ultimate 2027

Autodesk InfoDrainage Ultimate 2027 is a comprehensive drainage design and analysis software that supports BIM compliance with an optimized drainage design workflow. Version 2027 continues Autodesk’s legacy of integrated water management, offering tools for designing, optimizing, analyzing, and comparing drainage schemes – incorporating both traditional drainage elements and green infrastructure (SuDS, LID) as 3D objects. With bi-directional synchronization between InfoDrainage and Civil 3D (via part mapping), engineers can create pipe networks and surfaces in either platform and keep them updated seamlessly – reducing data errors and design iteration pain. Whether designing conventional piped systems, sustainable drainage features, or hybrid networks, InfoDrainage Ultimate delivers the analysis, visualization, and BIM interoperability that modern drainage engineering demands.

⚡ Key Features & Capabilities



????️ Integrated Drainage Design

Traditional Drainage Elements:

  • Pipes (circular, box, elliptical – concrete, HDPE, PVC, clay, metal)

  • Manholes, catch basins, inlets, outlets

  • Pumps, valves, weirs, orifice plates

  • Detention ponds, retention basins, swales

Green Infrastructure (SuDS / LID):

  • Rain gardens, bioretention cells, permeable pavement

  • Green roofs, infiltration trenches, soakaways

  • Vegetated swales, filter strips

  • Rainwater harvesting tanks

???? BIM & Civil 3D Integration

Bi-Directional Sync:

  • Pipe networks and surfaces can be created from InfoDrainage to Civil 3D (or vice versa)

  • Part mapping between InfoDrainage objects and Civil 3D parts

  • Maintain updateable links – reduce data transfer errors

  • Seamless round-trip workflows

BIM Compliance:

  • Optimized for BIM requirements (UK, international)

  • 3D objects for traditional and green infrastructure

  • Coordinate with architectural, structural, and civil models

???? Hydraulic & Hydrologic Analysis

Flow Calculations:

  • Rational method, Time-area, Unit hydrograph, SWMM runoff

  • Steady and unsteady flow routing (dynamic wave)

  • Inlet capacity, gutter flow, overland flow

Pipe & Channel Simulation:

  • Full pipe flow, partially full (open channel)

  • Backwater analysis, surcharging, flooding

  • Sediment transport / self-cleansing velocity checks

Pond & Detention Analysis:

  • Stage-storage-discharge routing

  • Orifice, weir, culvert, pump performance curves

???? Design Optimization & Comparison

  • Compare multiple drainage schemes (cost, flood risk, SuDS compliance)

  • Scenario manager (baseline vs. proposed)

  • Optimization parameters (pipe size, slope, pond volume)

???? Reporting & Compliance

Report Type Content
Long Sections Pipe invert, cover, ground profile
Flood Risk Exceedance flow paths, flood volumes
SuDS Compliance Water quality, volume reduction, peak flow control
Schedule / BOM Pipe lengths, manhole types, pond volumes

???? What’s New in Version 2027

  • Enhanced Civil 3D 2025-2027 Sync – Improved part mapping and round-trip update speed

  • Green Infrastructure Library – New bioretention, permeable pavement, rain garden templates

  • Climate Change Scenario – Design for future rainfall intensity (UKCP18, NOAA Atlas 15)

  • Water Quality Module – Pollutant load (TSS, TP, TN) and removal efficiency (SuDS)

  • Flood Map Export – Inundation extent (Shapefile, DXF) for master planning

???? System Requirements

Software Requirements

  • Host for BIM Sync: Autodesk Civil 3D 2025 (or newer)

  • OS: Windows 10/11 (64-bit)

  • Graphics: OpenGL 3.0 compatible with 64 MB RAM

???? Industry Applications

  • Residential & Commercial Development – Housing estates, retail parks, office complexes

  • Infrastructure (Roads, Highways) – Highway drainage, culverts, roadside ditches

  • Industrial & Logistics – Warehouses, factories, distribution centers

  • Urban Regeneration & Brownfield – Sustainable drainage (SuDS), water quality improvement

  • Climate Adaptation – Increased rainfall intensity, flood resilience
