HypsoCAD 2026 (HypsoBAR & Mascagni): On-Demand Dental CAD Suite

HypsoCAD 2026 is the latest version of the first on‑demand dental CAD software, designed to streamline digital restoration processes with a user‑friendly, guided workflow. The suite includes two specialized modules: HypsoBAR for designing implant‑supported bars, and Mascagni for general prosthetic design (crowns, bridges, inlays, and removable prosthetics).

???? Primary Users

This professional dental CAD software suite is designed for:

  • Dental Technicians & Laboratory Specialists designing implant bars, overdentures, crowns, bridges, and full prosthetics with flexible, on-demand tools

  • Implantologists & Prosthodontists planning and designing bar‑retained overdentures and All‑on‑X hybrid restorations

  • Dental Laboratory Owners seeking cost‑effective, subscription‑based CAD solutions with no long‑term commitments

  • Digital Dentistry Workflows integrating intraoral scanning, model creation, and 3D printing preparation

⚡ Key Features & Capabilities

???? HypsoBAR Module – Implant Bar Design

The Bar Module enables the design and fabrication of bar‑type prostheses, which can include crowns and bridges supported by prepared teeth or custom/threaded abutments and implants . The module allows for multiple bar shapes within one dental arch and features customizable bar profiles, attachment components, and retention elements.

Supported Bar Types:

  • Dolder bar (egg‑shaped cross‑section) – Allows three degrees of freedom (translation and rotational movements)

  • Round bar – Rigid unit permitting only one degree of freedom (translation)

  • Hader bar – Clip‑retained bar system for overdentures

  • Hybrid bar – For All‑on‑X full‑arch restorations with split denture workflow

  • Paris bar, Montreal bar, Wrap‑around bar, Free‑form milled bar – Various connector configurations for different clinical indications

Bar Design Features:

  • Bar pillars – Define implant or abutment positions

  • Bar segments – Connectors between pillars with customizable cross‑section profiles

  • Bar top height and width – Adjustable dimensions for optimal fit and strength

  • Bar base width and height – Configurable base dimensions for tissue adaptation

  • Distance to overdenture – Color‑coded visualization for optimal spacing

  • Height color map – Visual indicator of bar thickness compliance (red for areas too thin for production)

Retention & Attachment Features:

  • Retention elements – Add pins, bumps, notches, hooks, or protrusions directly onto bar surfaces to create retention for acrylic denture material

  • Retention orientation – Elements automatically oriented according to the normal surface of the bar at placement location; height and width independently adjustable via control axes or numerical entries

  • Attachments – Position clips, riders, and other attachment types using placement mode

  • Riders on the bar – Optional display for bar riders (acrylic retention structures)

  • Retention on Hybrid bars – Specialized retention placement for All‑on‑X restorations

Advanced Bar Customization:

  • Cylinder beveling – Bevel cylinders at custom angles using interactive control points

  • Link adjustment – Modify links to offset cylinders using deformation handles

  • Gingival surface verification – 2D cross‑section view to validate fit between bar base and soft tissue

  • Anterior region definition – Define the anterior region of Hybrid bars for proper esthetics

???? Mascagni Module – General Prosthetic Design

The Mascagni module provides comprehensive tools for designing:

  • Crowns & bridges – Single and multi‑unit restorations

  • Inlays, onlays & veneers – Conservative restorations

  • Implant prosthetics – Custom abutments, screw‑retained crowns, and bars

  • Removable prosthetics – Partial and complete dentures

???? Flexible Licensing Model

  • Starting at €79/month – Affordable entry point for laboratories

  • No hidden costs – Transparent pricing structure

  • No long‑term commitments – Flexible subscription terms

  • Perpetual free updates – Always have the latest features

  • Perpetual license option – Available for those preferring one‑time purchase

???? What’s New in HypsoCAD 2026

  • 2026‑1 Component Library – Updated implant and restoration component library released

  • Enhanced bar design workflows – Streamlined processes for complex bar cases

  • Updated component catalogs – New manufacturer parts added

  • Performance optimizations – Improved processing speed and stability
