SigmaNEST X1.4: 64-Bit CAD/CAM Nesting Software

igmaNEST X1.4 is a major release of SigmaTEK’s industry-leading CAD/CAM nesting software, introduced in 2018 . This version represents a significant milestone as the first 64-bit release, enabling the software to leverage more system memory for dramatically improved performance and faster processing of complex nesting jobs.

The software is designed to optimize material usage for various cutting processes including laser, plasma, waterjet, oxy-fuel, router, punch, and combination machines. It features a customizable ribbon toolbar, enhanced nesting engines, and integration with major ERP systems through the SimTrans Web module.

???? Primary Users

This professional CAD/CAM nesting software is designed for:

• Manufacturing & Fabrication Engineers optimizing material yield for laser, plasma, waterjet, and punch press operations.

• CNC Programmers & Machine Operators generating efficient toolpaths and NC code for cutting machines.

• Production Managers scheduling workloads, tracking jobs, and integrating with ERP systems.

• Job Shops & Sheet Metal Fabricators nesting parts to maximize material utilization and reduce waste.

• Industrial Manufacturing Companies producing complex parts from sheet metal, plate, or tube stock.

 Key Features & Capabilities



???? 64-Bit Architecture

• First SigmaNEST release to support 64-bit processing

• Takes advantage of more system memory for better performance

• Faster processing speeds and enhanced stability

• Handles larger, more complex nesting jobs efficiently

???? Customizable Ribbon Toolbar

• Users can create custom groups and display most-used functions

• Hide unused functions to streamline workflow

• Rearrange groups and functions within the toolbar

• One of the most frequently requested features since ribbon toolbar launch

???? Enhanced Nesting Engines

HD Rectangular Nesting Engine:

• Dynamic algorithm for nesting rectangular parts

• Average 3% increase in yield compared to standard rectangular engine

HD SuperNEST:

• Supports Best Sheet Options and Continuous Nesting module

• Available with new Powerpack Premium

• Saves up to 6% on material usage

???? Punching & Tooling Features

Auto Single Hit Function:

• Automatically tools all single hits for punch users

• Eliminates need to manually click on each contour

• Users can select tool types and apply to internal, external, or all contours

Multi-Drop Nesting Module:

• Nests common cut parts in columns

• Toolpath processes sheet from left to right

• Drop each column before moving to next

• Commonly used on Plate Processing machines

???? Integration & Data Management

SimTrans Web:

• Transaction management application

• Bridges gap between SigmaNEST and most major ERP systems

• Provides integrated experience for data exchange

Load Manager (64-bit):

• Production workload management tool

• Fully 64-bit compatible for increased speed

• Allows users to set shifts and breaks across all machines

• Optimized for slower networks

???? CAD & File Support

• Supports SolidWorks 2018 import

• Filtering of SolidWorks parts and assemblies by folder on import

• Advanced NC support for geometry-based clamps

• Automatically discard internal cutouts when creating medallion parts

???? International Support

• Help file translation with Google Translate plugin

• Available in 12 different languages

• Plugin accessible in all Help Centers

???? What’s New in X1.4
